INCREASED POWER: maximum thrust 2 tons (10 bars)
UPPER UNIVERSAL HOLD SYSTEM: allows all left/right-hand spring diameters to be compressed with one upper adaptable plate.
ACTIVE SAFETY SYSTEM ON SPRING: safety hook and 3 locking valves allow spring to be properly positioned/seated, maintaining such position throughout compression.
If spring is not positioned properly, system will stop machine.
PROTECTIVE “FULL BODY” GRILLE: provides maximum safety and working area coverage
CONTROL LEVER OPERATION: increased accuracy and sensitivity during compression stage
WORKING POSITION: working height on rear fork raised up to 875 mm
Supplied with 2 lower forks for diameters 78-205 mm
TECHNICAL DATA
Maximum thrust: 2 tons (10 bars) – 1.6 tons (8 bars) – 1.2 tons (6 bars)
Spring compression stroke: 335 mm
