1635-S

Closed end connector terminals, for free connections

Stated prices are for individual 10-way bars. Minimum quantity: 10 pcs

Insulating housing: transparent polycarbonate UL94 V0
Conductive body: brass
Captive screw: galvanized steel
Self-extinguishing: EN60695-2-10 a 850°C, EN 60335-1:2002 +A2:2006, EN60695-2-11
Working temperature: max. 85 °C
Degree of protection: IP20
Reference standards: EN60998-1: EN60998-2-1:2004

Images with dimensions

Product Name
Art.
mm²
mm²
L mm
L1 mm
S mm
N
BM991
BM991
1.5 1 0.75
1.5
15
7.5
14.5
2 2÷3 2÷4
BM992
BM992
2.5 1.5 1
2.5
17.5
9
18.2
2 2÷3 2÷4
BM9924
BM9924
4 2 1.5
4
21
10.3
20
2 2÷3 2÷4
BM993
BM993
6 4 2.5
6
22.5
11.8
23
2 2÷3 2÷4
BM994
BM994
10 6 4
10
26
14.7
26
2 2÷3 2÷4
BM995
BM995
16 10 6
16
31.8
18.8
32.2
2 2÷3 2÷4
BM9960
BM9960
25 16 10
25
36.3
22.5
41.9
2 2÷3 2÷4
BM9961
BM9961
35 25 16
35
43.5
26.1
49.4
2 2÷3 2÷4
